AEM Performance Electronics CD-7 - Compatible Sensor and Accessory Part Numbers

57
Compatible Sensor and Accessory Part Numbers
The following is a list of compatible sensors and accessories.
AEM PN
Description
30-2065
K-Type Closed Tip Thermocouple Sensor Kit. Inconel Sheath. 1/8" NPT Compression Fitting. Includes: K-
Type Closed Thermocouple Sensor, 1/8" Compression Fitting & Ring Terminal Harness
30-2066
K-Type Closed Tip Thermocouple 10' Wiring Extension Kit. Includes: 10' Wiring Extension, 2 X 4-40 Hex Nut,
2 X 4-40 Screw & 6" Heat Shrink Tubing
30-2068
30-2068-2
30-2068-4
K-Type Closed Tip Thermocouple Kit. Inconel Sheath. 1/8" NPT Compression Fitting. Includes: AEM Part
Numbers 30-2065 & 30-2066, (-2) and (-4) versions include either 2 or 4 sensor and extension
combinations
30-3606
AEMNet Extension Cable 2 feet Kit
30-3607
AEMNet Extension Cable 5 feet Kit
30-3608
AEMNet Extension Cable 10 feet Kit
35-3440-F
AEMnet Female Termination Plug
35-3440-M
AEMnet Male Termination Plug
35-2624
DTM-Style 4-Way Plug Connector Kit. Includes Plug, Plug Wedge Lock & 5 Female Pins
35-2625
DTM-Style 4-Way Receptacle Connector Kit. Includes Receptacle, Receptacle Wedge Lock & 5 Male Pins
35-2626
DTM-Style 4-Way Connector Kit. Includes Plug, Receptacle, Plug Wedge Lock, Receptacle Wedge Lock, 5
Female Pins & 5 Male Pins
Specifications
Dimensions
width
1.8 / 45.8
in / mm
length (excl. connector)
4.0 / 103
in / mm
height
1.4 / 35
in / mm
mass
3.8 / 110
oz / g
Supply Voltage
min
7
VDC
max
18
VDC
Supply Current (13.8V)
nominal
70
mA
Operating Temperature
min
-4 / -20
degF / degC
max (16V Supply)
185 / 85
degF / degC
K-Type
Thermocouple Inputs
Input Protection
+/- 45
VDC
Minimum
-328 / -200
degF / degC
Maximum
2501 / 1372
degF / degC
Resolution
0.1
degC
Full-Scale Error
+/- 0.15 (Max)
%
CAN Transmit Rate
10
Hz
Cold Junction Sensor
Minimum
-67 / -55
degF / degC
Maximum
257 / 125
degF / degC
Resolution
0.1
degC
Accuracy
+/- 0.7 (Max)
degC
CAN Transmit Rate
2
Hz
CAN
Bit Rate (User Configurable)
250 / 500 / 1000
kb/s
