24
Course over ground, NOT heading
"Visible" number of satellites
1 = Valid Fix, 0 = No Fix
Accelerometer / Gyroscope
The following accelerations and yaw rate channels are output on AEMnet for logging on your Infinity ECU or other
device:
*If +x is mounted in the direction of travel
6 Channel CAN Sensor Module to Dash
Kit Contents
The AEM 6 Channel CAN Sensor Module enables a user to put analog, fuel level, and tachometer signals onto an
AEMnet or CAN bus. The Sensor Module accommodates a wide variety of sensors and is housed in a sealed IP67
weather-resistant enclosure. Sturdy construction, protected inputs, and simple configuration make this the perfect
entry point to get everything required to use an AEM CD-series dash on a carbureted or EFI vehicle. The Sensor
Module supports the Bosch CAN 2.0b standard making it compatible with many third-party devices. Note: The only
AEMnet devices that are compatible with the CAN Sensor Module are the CD-series dash displays.
Features
·
Two (2) temperature (thermistor) inputs
·
Two (2) dedicated 0-5V analog inputs
·
One (1) dedicated fuel level input (0 to 250 Ohm
range)
·
One (1) tachometer/coil input
·
Fixed CAN bus speed, header length, and base
address
·
IP67 Potted Enclosure / Sealed Connector - "dust
tight" and protected against water spray
·
Protected inputs
MODULE, 6 CHANNEL CAN SENSOR MODULE
INST, MODULE, 22 CHANNEL CAN SENSOR
MODULE
CONNECTOR, SLD, 12-WY PLG A
TERMINAL, SKT, SZ 20, .05-.08
