AEMnet (CAN Bus) Output
WHITE WIRE = AEMnet+ / CANH
GREEN WIRE = AEMnet- / CANL
CAN DBC definition files are available at
www.aemelectronics.com
Bus Termination
All AEMnet/CAN networks must be terminated to have
an equivalent of approximately 60 Ohms of resistance.
Generally, this means a 120 Ohm resistor connected in
parallel to AEMnet+/AEMnet- (or CANH/CANL) at both
physical ends of the bus run.
bit rate
500
kb/sec
format
29
bit ID
terminating resistor
None
endianness
big / Motorola
DLC
8
0x0000B600 at 100Hz
Byte
Label
Data Type
Scaling
Offset
Range
0
Analog1
16 bit unsigned
1 Ohm/bit
0
0 to 65535 Ohm
1
2
Analog2
16 bit unsigned
1 Ohm/bit
0
0 to 65535 Ohm
3
4
Analog3
16 bit unsigned
0.001 V/bit
0
0 to 65.535 V
5
6
Analog4
16 bit unsigned
0.001 V/bit
0
0 to 65.535 V
7
0x0000B601 at 50Hz
Byte
Label
Data Type
Scaling
Offset
Range
0
Tacho
16 bit unsigned
0.1 Hz/bit
0
0 to 6553.5 Hz
1
2
n/a
n/a
n/a
n/a
n/a
3
4
n/a
n/a
n/a
n/a
n/a
5
6
FuelLevel
8 bit unsigned
1 Ohm/bit
0
0 to 255 Ohm
7
Battery Voltage
8 bit unsigned
0.1 V/bit
0
0 to 25.5 V
22 Channel CAN Sensor Module to Dash
Kit Contents
The AEM 22 Channel CAN Sensor Module enables a user to put analog, digital, and frequency signals on to an
AEMnet or CAN bus. The Sensor Module accommodates a wide variety of sensors and is housed in a sealed IP65
weather-resistant enclosure. Sturdy construction, protected inputs, and simple configuration make this the perfect
entry point to get everything required to use an AEM CD-series dash on a carbureted or EFI vehicle. The Sensor
Module supports the Bosch CAN 2.0b standard with flexible CAN configuration jumpers making it compatible with
many third-party devices. Note: The only AEMnet devices that are compatible with the CAN Sensor Module are the
CD-series dash displays.
Features
· Four (4) dedicated 0-5V analog inputs
· Four (4) user-configurable analog inputs, (jumper
selectable; 0-5V, thermistor, or RTD)
· Four (4) temperature (thermistor) inputs
· One (1) dedicated fuel level input (0 to 250 Ohm
range)
PN
QTY
Description
35-2212
1
MODULE, 22 CHANNEL CAN SENSOR MODULE
10-2212
1
INST, MODULE, 22 CHANNEL CAN SENSOR
MODULE
