· Six (6) digital inputs (frequency, duty cycle or
simple switch)
· One (1) tachometer/coil input
· Two (2) VR ("magnetic") pair frequency inputs
(crank, wheel or drive shaft speeds)
· Jumper selectable CAN bus speeds: 250k, 500k,
1M
· Jumper selectable terminating resistor
· Jumper selectable header length, 11 bit or 29 bit
· Jumper selectable base address, two units can be
on the same bus
· IP65 Enclosure - "dust tight" and protected against
water spray
· Protected inputs
36-2212
1
HARNESS, MODULE, 22 CHANNEL CAN
SENSOR MODULE
4-0126
12
WIRE TERM, 22 AWG YELLOW
4-0127
3
WIRE TERM, 22 AWG RED
4-0128
5
WIRE TERM, 22 AWG BLK
4-0129
6
WIRE TERM, 22 AWG TAN
4-0130
6
WIRE TERM, 22 AWG WHT
4-2069
10
TERMINAL, F, MICRO-PACK 20-22 AWG
4-3027
10
SEAL, BLUE, MICRO-PACK 100W
Installation
Mechanical
The Sensor Module may be mounted within the vehicle using hook-and-loop fastener or bolted to a suitable
structure; a mounting/drill diagram is provided below. The module is weather-resistant (IP65) but is preferably
mounted in a cool, dry area such as the driver compartment.
