50
Specifications
Dimensions
width
4.7 / 120
in / mm
length
4.3 / 110
in / mm
height
1.4 / 36
in / mm
mass
6.3 / 180
oz / g
Supply Voltage
min
7
VDC
max
18
VDC
Supply Current (13.8V)
nominal
165
mA
Operating Temperature
min
-4 / -20
degF / degC
max (16V Supply)
185 / 85
degF / degC
5V Sensor Supply
Current
250
mA
Analog Inputs 1 - 4
Range
0 - 5
VDC
Resolution
0.001 (12-bit)
VDC
Pull-up (5V)
100,000
Ohm
CAN Transmit Rate (Unit 1)
100
Hz
CAN Transmit Rate (Unit 2)
50
Hz
Analog Inputs 5 - 8
Range
0 - 5
VDC
Resolution
0.001 (12-bit)
VDC
Range
0 - 65535
Ohm
Resolution
1 (12-bit)
Ohm
Selectable Pull-up (5V)
470, 2200, or 100000
Ohm
CAN Transmit Rate (Unit 1) [Voltage/ Resistance]
100 / 10
Hz
CAN Transmit Rate (Unit 2) [Voltage / Resistance]
50 / 5
Hz
Analog Inputs 9 - 12
Range
0 - 65535
Ohm
Resolution
1 (12-bit)
Ohm
Pull-up (5V)
2,200
Ohm
CAN Transmit Rate (Unit 1)
10
Hz
CAN Transmit Rate (Unit 2)
5
Hz
Fuel Level Input
Range
0 - 255
Ohm
Resolution
1 (12-bit)
Ohm
Pull-up
5
VDC
CAN Transmit Rate (Unit 1)
50
Hz
CAN Transmit Rate (Unit 2)
25
Hz
VR Inputs 1 - 2
Range
0 - 15000
Hz
Resolution
1
Hz
CAN Transmit Rate (Unit 1)
50
Hz
CAN Transmit Rate (Unit 2)
25
Hz
Tachometer Input
Range
0 - 1500
Hz
Resolution
0.1
Hz
Pull-up
12
VDC
Minimum Trigger Voltage
3
VDC
Maximum Voltage (Sustained)
18
VDC
CAN Transmit Rate (Unit 1)
50
Hz
CAN Transmit Rate (Unit 2)
25
Hz
Digital Inputs 1 - 6
Frequency Range
0 - 15000
Hz
Frequency Resolution
1
Hz
Duty Cycle Range
0 - 100
%
Duty Cycle Resolution
1
%
Minimum Trigger Voltage
7.5
VDC
Maximum Voltage
18
VDC
Pull-up
12
VDC
