6.2. TECHNICAL DATA NS 2002 … 3402
NOMINAL REFERENCE CONDITIONS
Inlet water temperature 12°C
Outlet water temperature 7°C
Outside air temperature d.b. 35°C
Δt 5°C
NS Vers. U.M. 2002 2202 2352 2502 2652 2802 3002 3202 3402
Cooling capacity:
°
kW
404 450 486 503 541 578 629 671 721
L 372 420 443 459 495 530 573 616 669
A 450 495 519 543 577 612 661 695 767
E 410 453 478 503 539 574 622 660 721
Total input power
° 154 171 177 187 202 216 225 235 262
L 160 181 185 198 211 230 237 248 274
A 144 157 166 173 182 197 201 208 238
E 150 161 171 181 192 207 210 218 249
Evaporator water flow rate
°
l/h
69490 77400 83590 86520 93050 99420 108190 115410 124010
L 63980 72240 76200 78950 85140 91160 98560 105950 115070
A 77400 85140 89270 93400 99240 105260 113690 119540 131920
E 70520 77920 82220 86520 92710 98730 106980 113520 124010
Evaporator pressure drops
°
kpa
36 40 48 50 47 53 44 38 50
L 313540423945373243
A 443942464855322535
E
37 33 36 39 42 48 28 23 31
ENERGY INDICES
EER
°
W/W
2,62 2,63 2,74 2,70 2,68 2,67 2,79 2,86 2,75
L 2,32 2,33 2,39 2,32 2,34 2,30 2,41 2,48 2,44
A 3,13 3,15 3,13 3,14 3,17 3,11 3,29 3,34 3,22
E 2,73 2,81 2,80 2,78 2,81 2,77 2,96 3,03 2,90
ESEER
° 3,59 3,56 3,82 3,81 3,73 3,78 3,68 3,68 3,68
L 3,48 3,45 3,71 3,70 3,62 3,67 3,57 3,57 3,57
A 4,23 4,24 4,23 4,25 4,25 4,21 4,28 4,30 4,26
E
4,10 4,11 4,10 4,12 4,12 4,08 4,15 4,17 4,13
ELECTRICAL DATA
Total input current
°
A
261 295 306 322 347 371 384 394 435
L 266 301 310 333 354 381 398 411 450
A 248 274 288 301 320 339 353 362 403
E 247 277 290 303 320 344 352 364 407
Maximum current
°/L 372 392 425 458 458 458 472 472 567
A/E 372 392 425 458 458 458 472 472 567
Peak current
°/L 403 420 480 507 551 553 567 567 628
A/E
410 427 487 514 558 560 567 567 635
Charge
Oil kg 15 + 22
22 + 22 22 + 19 19 + 19 19 + 19 19 + 19 19 + 19 19 + 19 19 + 35
COMPRESSOR (TWIN-SCREW)
No. of compressors/circuits ALL no./no. 2/2
Capacity control
Standard thermostatic valve
% 40-100
Capacity control
Electronic thermostatic valve
%
25-100
FANS (AXIAL)
Quantity
°/L
n°
888888121212
A/E 10 10 10 10 10 10 12 12 14
Total input power
°/L
kW
11,2 11,2 11,2 11,2 11,2 11,2 16,8 16,8 16,8
A/E 14 14 14 14 14 14 16.8 16.8 19.6
Total input current
°/L
A
24 24 24 24 24 24 36 36 36
A/E 30 30 30 30 30 30 36 36 42
Air fl ow rate
°
m³/h
145000 145000 145000 145000 152000 152000 226000 220000 220000
L 104000 104000 104000 104000 108000 108000 164000 164000 164000
A 187500 180000 176500 173000 173000 173000 212000 212000 242000
E
124500 120000 123000 126000 130000 136000 155500 163000 175500
