AERMEC 2002 - Carpentry by 4770 mm

INSPY. 1003. 4138305_03
50
19.2. CARPENTRY BY 4770 (mm)
NS 2101 - 2401
°°(°/L°°00…PA…PK)
NS
1801 °°(A/E°°00…PA…PK)
NS 2002 - 2202 - 2352 - 2502 °°(°/L°°00…PA…PK)
NS 1802 °°(A/E°°00…PA…PK)
WARNING:
ALWAYS USE ALL THE
PROVIDED EYEBOLTS
FOR THE LIFTING OF
THE UNIT
1
7
3 5
8
2 4 6
400 365 1460
400 4370
4770
2200
550 5501100 2170
1460 365
50 2100
100
50
1002000
2450
720
2200
POSITION OF VIBRATION DAMPERS
POSITION FOR LIFTING
