19. DIMENSIONAL TABLES CARPENTRY BY 3780 (mm)
19.1. CARPENTRY BY 3780 (mm)
NS 1251 - 1401 - 1601 - 1801
°°(°/L°°00…PA…PK)
NS
1251 - 1401 - 1601 °°(A/E°°00…PA…PK)
NS 1402 - 1602 - 1802 °°(°/L°°00…PA…PK)
NS 1402 - 1602 °°(A/E°°00…PA…PK)
WARNING:
ALWAYS USE ALL THE
PROVIDED EYEBOLTS
FOR THE LIFTING OF
THE UNIT
3380
3780
2200400
2280550 550
365
50
100
50
100
2100
2000
2450
365400
2200
1 7
8
2
POSITION OF VIBRATION DAMPERS
POSITION FOR LIFTING
