6.3. TECHNICAL DATA NS 3602 … 5702
NS Vers. U.M.
3602 3902 4202 4502 4802 5002 5202 5402 5702
Cooling capacity:
°
kW
771 828 879 936 987 1063 1140 1185 1230
L 722 773 815 866 907 984 1060 1105 1150
A 839 885 953 999 1066 1155 1244 1287 1330
E 782 822 888 928 994 1088 1160 1198 1236
Total input power
°
kW
290 311 324 345 359 390 420 432 444
L 300 320 335 355 370 405 440 454 467
A 268 284 298 314 329 360 390 408 426
E 280 295 312 327 344 376 407 426 444
Evaporator water flow rate
°
l/h
132610 142420 151190 160990 169760 182838 196082 203822 211562
L 124180 132960 140180 148950 156000 169250 182322 190062 197802
A 144310 152220 163920 171830 183350 198662 213970 221366 228763
E 134500 141380 152740 159620 170970 187138 199522 206058 212594
Evaporator pressure drops
°
kPa
58 46 50 40 43 40 36 39 42
L 514043343634313437
A 454146434742373942
E
39 35 40 37 41 37 32 34 36
ENERGY INDICES
EER
°
W/W
2,66 2,66 2,71 2,71 2,75 2,73 2,71 2,74 2,77
L 2,41 2,42 2,43 2,44 2,45 2,43 2,41 2,44 2,46
A 3,13 3,12 3,20 3,18 3,24 3,21 3,19 3,15 3,12
E 2,79 2,79 2,85 2,84 2,89 2,89 2,85 2,82 2,78
ESEER
°
W/W
3,68 3,73 3,73 3,73 3,67 3,71 3,71 3,69 3,69
L 3,57 3,62 3,62 3,62 3,56 3,60 3,60 3,58 3,58
A 4,19 4,18 4,24 4,17 4,17 4,25 4,26 4,20 4,15
E
4,06 4,05 4,11 4,04 4,04 4,12 4,13 4,07 4,03
ELECTRICAL DATA
Total input current
°
A
477 519 540 582 603 648 693 715 736
L 488 527 551 591 613 670 726 750 774
A 444 478 501 535 558 614 655 685 715
E 450 480 508 538 566 626 670 700 735
Maximum current
°/L
A
662 679 719 736 776 866 924 968 1012
A/E 676 693 733 750 790 880 938 975 1012
Peak current
°/L
A
654 778 825 900 900 1051 1109 1228 1227
A/E
661 792 839 914 914 1065 1123 1235 1227
Charge
Oil kg
35 + 35 35 + 35 35 + 35 35 + 35 35 + 35 35 + 35 35 + 35 35 + 35 35 + 35
COMPRESSOR (TWIN-SCREW)
No. of compressors/circuits ALL no./no. 2/2
Capacity control
Standard thermostatic valve
% 40-100
Capacity control
Electronic thermostatic valve
%
25-100
FANS (AXIAL)
Quantity
°/L
n°
12 14 14 16 16 16 16 18 20
A/E 16 18 18 20 20 20 20 20 20
Input power
°/L
kW
16.8 19.6 19.6 22.4 22.4 22.4 22.4 25.2 28
A/E 22.4 25.2 25.2 28 28 28 28 28 28
Input current
°/L
A
36 42 42 48 48 48 48 54 60
A/E 48 54 54 60 60 60 60 60 60
Air fl ow rate
°
m³/h
220000 260000 255000 295000 290000 297000 304000 324000 360000
L 164000 192000 186000 214000 208000 212000 216000 240000 267000
A 272000 316000 310000 354000 348000 346000 346000 346000 346000
E 188000 207000 212000 231000 236000 254000 272000 283500 295000
NOMINAL REFERENCE CONDITIONS
Inlet water temperature 12°C
Outlet water temperature 7°C
Outside air temperature d.b. 35°C
Δt 5°C
