AERMEC 2002 User Manual

INSPY. 1003. 4138305_03
20
NS Vers. U.M. 2002 2202 2352 2502 2652 2802 3002 3202 3402
EXPANSION TANK
Capacity dm
3
25
Calibration pressure Bar 1.5
Quantity n° 24
SOUND DATA
Sound power
°
dB(A)
98 98 97 98 98 98 99 99 99
L 909090909091909191
Sound pressure
° 65,6 65,6 64,6 65,6 65,5 65,5 66,4 66,4 66,4
L 57,6 57,6 57,6 57,6 57,5 58,5 57,4 58,4 58,4
Sound power
A 989897989898999999
E 909090909091909191
Sound pressure
A 65,5 65,5 64,5 65,5 65,5 65,5 66,4 66,4 66,3
E 57,5 57,5 57,5 57,5 57,5 58,5 57,4 58,4 58,3
DIMENSIONS°/L
Height
All
mm
2450 2450 2450 2450 2450 2450 2450 2450 2450
Width
°/L
2200 2200 2200 2200 2200 2200 2200 2200 2200
Depth 4770 4770 4770 4770 5750 5750 7160 7160 7160
Weight when empty
Kg
4270 4740 4800 4900 5320 5330 6180 6270 6770
Weight when empty with desuper-
heater
4310 4790 5190 5360 5380 5390 6240 6340 6840
Weight when empty with total heat
recovery
4556 5026 5119 5219 5705 5715 6620 6710 7254
Weight during operation 4378 4848 4908 5008 5423 5433 6331 6418 6918
DIMENSIONS A/E
Height
All
mm
2450 2450 2450 2450 2450 2450 2450 2450 2450
Width
A/E
2200 2200 2200 2200 2200 2200 2200 2200 2200
Depth 5750 5750 5750 5750 5750 5750 7160 7160 8150
Weight when empty
Kg
4700 5270 5390 5500 5510 5520 6450 6520 7540
Weight when empty with desuperheater 4740 5320 5440 5550 5570 5580 6510 6590 7610
Weight when empty with total heat
recovery
4986 5556 5709 5819 5895 5905 6890 6960 8024
Weight during operation 4808 5373 5493 5603 5608 5618 6630 6732 7759
Sound power
Aermec determines the sound power value on the
basis of measurements taken in accordance with
standard 9614-2, in compliance with the Eurov-
ent certification.
Sound pressure
Sound pressure in an unrestricted range on a reflec-
tive plane (directional fact. Q=2), 10m away from
the unit external surface, complying with ISO 3744.
