7. OPERATING LIMITS
The devices in their standard configura-
tions are not suitable for installation in
salty environments.
For the operating limits, refer to dia-
gram, valid for ∆t = 5°C.
NOTE
Contact our technical sales depart-
ment if the unit needs to operated
outside the operating limits
Wind breaks should be implemented if
the unit is installed in particularly windy
areas, to prevent a malfunction of the
DCPX
-6
-10
-5
0
5
10
15
20
25
30
35
40
42
50
-4 1514131211109876543210-2
42
42
38
-6
-10
-5
0
5
10
15
20
25
30
35
40
48
50
-4 1514131211109876543210-2
48
48
44
Standard operation
Standard operation
Standard operation
Operation with
glycol and with
DCPX accessory
Operation with
glycol and with
DCPX accessory
Operation with
glycol and with
DCPX accessory
Operation with DCPX
accessory
Operation with DCPX
accessory
Operation with DCPX
accessory
Operation with
glycol
Operation with
glycol
Operation with
glycol
Processed water temperature °C
Processed water temperature °C
Processed water temperature °C
Outside air temp. bs °C Outside air temp. bs °C Outside air temp. bs °C
COOLING
Side
High
pressure
Side
Low
pressure
Maximum
pressure
allowable
bar
22 16,5
Maximum
temperature
allowable
°C 120 55
Minimum
temperature
allowable
°C -10 -10
7.1. OPERATING LIMITS GRAPH VERSIONS «° and L»
7.2. OPERATING LIMITS GRAPH VERSIONS «A and E» for 5402-5702
7.3. DESIGN DATA
7.4. OPERATING LIMITS GRAPH VERSIONS «A and E»
