AERMEC 2002 User Manual

INSPY. 1003. 4138305_03
69
19.10.1. POSITION WATER CONNECTIONS
NS4502-4802°°(A/E°°00…PA…PK)
19.10.2. POSITION WATER CONNECTIONS
NS5702°°(°/L°°00…PA…PK)
NS 5202-5402-5702°°(A/E°°00…PA…PK)
19.10.3. POSITION WATER CONNECTIONS
NS 5002 (A/E°°00…PA…PK)
FOR EVAPORATOR connections version «00»
FOR PUMP connections ver «PA...PK»
FOR DESUPERHEATER connections version «D»
IN DES Ø 2"
IN DES Ø 2"
OUT DES Ø 2"
IN PUMPS Ø 6"
OUT WATER Ø 6"
OUT WATER Ø 6"
IN WATER Ø 6" VER.00
OUT DES Ø 2"
IN WATER Ø 6"
VER.00
IN PUMPS Ø 6"
IN DES Ø 2"
IN DES Ø 2"
OUT DES Ø 2" IN PUMPS Ø 6"
OUT WATER Ø 6"
OUT WATER Ø 5"
IN WATER Ø 6" VER.00
OUT DES Ø 2"
IN WATER Ø 5"
VER.00
IN PUMPS Ø 5"
KEY
All connections are VICTAULIC supplied
together with joints to weld
KEY
All connections are VICTAULIC supplied
together with joints to weld
KEY
1. OUT Evaporator ø 5"
2. IN Evaporator ø 5"
3. IN PUmp ø 5"
All connections are VICTAULIC supplied
together with joints to weld
1691 1652
893
24502007
2007
5350
1691 1652
893
24502007
2007
5350
366
758 pump G/H/J/K
778
pump A/B/C/D/E/F
758 pump G/H/J/K
778
pump A/B/C/D/E/F
758
758
366
FOR EVAPORATOR connections version «00»
FOR PUMP connections ver «PA...PK»
FOR EVAPORATOR connections version «00»
FOR PUMP connections ver «PA...PK»
FOR DESUPERHEATER connections version «D»
