19.11. CARPENTRY BY 10120 (mm)
NS 5002 °°(°/L°°00…PA…PK)
WARNING:
ALWAYS USE ALL THE
PROVIDED EYEBOLTS
FOR THE LIFTING OF
THE UNIT
POSITION OF
VIBRATION
DAMPERS
STRUT POSITION FOR LIFTING
1) the weight of the
pumps to be added
to the version without
hydronic kit
− PA 69 Kg
− PB 138 Kg
− PC 75 Kg
− PD 150 Kg
− PE 91 Kg
− PF 182 Kg
− PG 100 Kg
− PH 200 Kg
− PJ 108 Kg
− PK 216 Kg
NS
Heat recovery
Version
Hydronic kit
(1)
Weight and centre
of gravity
when empty
(kg)
Support 1
Support 2
Support 3
Support 4
Support 5
Support 6
Support 7
Support 8
Support 9
Support 10
Support 11
Support 12
Support 13
Support 14
Support 15
Support 16
Kit AVX
kgx y %%%%%%%%%%%%%%%%
5002 ° °/L 00 9360 4674 1212
4.8
5.9 11.7 14.3 / /
2.3 2.8 6.3 7.7 9.9 12.1 5.4 6.7 4.5 5.5 535
5002 D °/L 00 9480 4674 1212
4.8
5.9 11.7 14.3 / /
2.3 2.8 6.3 7.7 9.9 12.1 5.4 6.7 4.5 5.5 535
5002 T °/L 00 --------------------
Lato evaporatori
Lato compressori
Lato evaporatori
Lato compressori
Lato evaporatori
Lato compressori
0
x
y
YG
XG
