AERMEC 2002 User Manual

INSPY. 1003. 4138305_03
25
NS Vers. U.M. 6003 6303 6603 6903 7203
ENLARGED FANS (AXIAL)
Quantity
°/L
n°
20 22 22 24 24
A/E 26 28 28 30 30
Input power
°
kW
40 44 44 48 48
L 26 28,6 28,6 31,2 31,2
A 5256566060
E 33,8 36,4 36,4 39 39
Input current
°
A
80 88 88 96 96
L 52 57,2 57,2 62,4 62,4
A 104 112 112 120 120
E 67,6 72,8 72,8 78 78
Air fl ow rate
°
m³/h
365000 405000 400000 440000 435000
L 268000 296000 290000 318000 312000
A 446000 490000 484000 528000 522000
E
306000 325000 330000 349000 354000
FANS INVERTER (AXIAL)
Quantity
°/L
n°
20 22 22 24 24
A/E 26 28 28 30 30
Input power
°
kW
40 44 44 48 48
L 26 28,6 28,6 31,2 31,2
A 5256566060
E 33,8 36,4 36,4 39 39
Input current
°
A
80 88 88 96 96
L 52 57,2 57,2 62,4 62,4
A 104 112 112 120 120
E 67,6 72,8 72,8 78 78
Air fl ow rate
°
m³/h
365000 405000 400000 440000 435000
L 268000 296000 290000 318000 312000
A 446000 490000 484000 528000 522000
E
306000 325000 330000 349000 354000
EVAPORATOR (TUBE CORE)
Water contents
°/L
dm
3
74+74 +165 74+106+ 165 74+165+165 106+165 +165 165+165 +165
A/E 113+113+ 165 113+165+165 113+165+165 165+165+165 165+165+165
Water connections (VICTAULIC)
°/L
ø
4"+4"+5" 4"+4"+5" 4"+5"+5" 4"+5"+5" 5"+5"+5"
A/E 4"+4"+5" 4"+5"+5" 4"+5"+5" 5"+5"+5" 5"+5"+5"
Electric resistor (Effi ciency/std/opt.)
øNO
Water fi lter (dim/std/opt.)
Quantity n° 3 3 3 3 3
DESUPERHEATERS (PLATE HEAT) OPTIONAL
Recovered effi ciency
°
kW
315 330 342 357 369
L 294 307 317 330 340.5
A 343 354.7 371.5 383 400
E 319.5 330 346 356 372.5
Quantity all n° 3 3 3 3 3
Water fl ow rate
°
l/h
54180 56760 58824 61404 63468
L 50568 52804 54524 56760 58566
A 58996 61008 63898 65876 68800
E 54954 56760 59512 61232 64070
Pressure drop of the exchanger all kPa 4 4 4 4 4
Water connections (VICTAULIC) Ø
2"
Desuperheater weight All kg 80 + 60 90+60 90+60 110+60 120+60
HEAT RECOVERY (PLATE HEAT) OPTIONAL
Recovered effi ciency
°
kW
1768 1827 1910 1969 2051
L 1768 1827 1910 1969 2051
A 1768 1827 1910 1969 2051
E 1768 1827 1910 1969 2051
Quantity All n° 3 3 3 3 3
Water fl ow rate All l/h 304096 314244 328520 338668 352772
Pressure drop of the exchanger All kPa 55 59 60 63 65
Water connections (VICTAULIC) Ø
4"
Weight All kg 847 869 902 924 957
PUMP/S No. 1 - 2 x circuit OPTIONAL
PUMPS
PA PC PE PG PJ
Input power kW 4 5,5 7,5 9,2 11
Input current A 5,5 7,5 10 12,5 15
Weight kg 109 117 121 140 148
Water connections (VICTAULIC)
According to the fitted evaporator
NOMINAL REFERENCE CONDITIONS
DESUPERHEATER
Outlet water temperature 45°C
Δt 5°C
TO THE TOTAL RECOVERY
Outlet water temperature 45°C
Δt 5°C
