19.12.1. POSITION WATER CONNECTIONS
NS5202°°(°/L°°00…PA…PK)
FOR EVAPORATOR connections version «00»
FOR PUMP connections ver «PA...PK»
FOR DESUPERHEATER connections version «D»
IN DES Ø 2" IN DES Ø 2"OUT DES Ø 2"
IN PUMPS Ø 6"
OUT WATER Ø 6"
OUT WATER Ø 6"
IN WATER Ø 6" VER.00
OUT DES Ø 2"
IN WATER Ø 6"
VER.00
IN PUMPS Ø 6"
KEY
All connections are VICTAULIC supplied
