19.14.1. POSITION WATER CONNECTIONS
NS6303°°(°/L°°00…PA…PK)
19.14.2. POSITION WATER CONNECTIONS
NS6603°°(°/L°°00…PA…PK)
FOR EVAPORATOR «00»
FOR PUMP «PA...PK»
KEY
MODULE C
1. OUT Evaporato 5"
2. IN Evaporator 5"
3. IN Pumps 5"
MODULE B
1. OUT Evaporator 4"
2. IN Evaporator 4"
3. IN Pumps 4"
MODULE A
1. OUT Evaporator 4"
2. IN Evaporator 4"
3. IN Pumps 4"
A
BC
758 pump G/H/J/K
778
pump A/B/C/D/E/F
758
366
4370
16911027
1027
2450
893
1652
4370
16911027
1027 2450 893
1652
934
934 506 1940
1536
910
3380
337
710
710 pump G/H/J/K 730 pump A/B/C/D/E/F
KEY
MODULE C
1. OUT Evaporator 5"
2. IN Evaporator 5"
3. IN Pumps 5"
MODULE B
1. OUT Evaporator 5"
2. IN Evaporator 5"
3. IN Pumps 5"
MODULE A
1. OUT Evaporator 4"
2. IN Evaporator 4"
3. IN Pumps 4"
A
BC
FOR EVAPORATOR «00»
FOR PUMP «PA...PK»
