INSPY. 1003. 4138305_03

89

Table of Contents

Default Chapter4
- Table of Contents4
1 General Warnings8
- Conserving the Documentation8
- Safety Precautions and Installation8
2 Product Identiﬁ Cation8
3 Description and Choice of the Unit8
- Models Available8
- Available Versions8
- Description and Choice of the Unit9
4 Components Description10
- Chiller Circuit10
- Frame and Fans10
- Hydraulic Components11
- Safety and Control Components11
- Electrical Components11
- Electronic Regulation12
5 Accessories13
- Electric Regulation Accessories13
- Electrical Accessories13
- General Accessories13
6 Technical Data15
- Technical Data Ns 125115
- Technical Data Ns 200218
- Technical Data Ns 360221
- Technical Data Ns 600324
7 Operating Limits27
- Operating Limits Graph Versions «° and L27
- Operating Limits Graph Versions «A and E» for 5402-570227
- Design Data27
- Operating Limits Graph Versions «A and E27
8 Correction Factors28
- Standard Version28
- Standard Version in Silenced Form28
- High Efﬁ Ciency Version Except for the Sizes 5402 and 570229
- High Efﬁ Ciency Version in Silenced Version Except for the Sizes 5402 and 570229
- High Efﬁ Ciency Version Except for the Sizes 5402 and 570230
- High Efﬁ Ciency Version in Silenced Version Except for the Sizes 5402 and 570230
- For Δt Different from the Rated Value31
- Fouling Factors31
9 Glycol32
- How to Read the Glycol Curves32
10 Total Pressure Drops33
- Minimum Water Content Recommended33
11 Desuperheater37
- Pressure Drops37
12 Total Recovery38
- Pressure Drops38
- Pressure Drops Total Recovery38
13 Pumps39
- Selection of Pumps39
14 Sound Data40
- Sound Levels at Full Load Standard NS40
- Sound Levels at Full Load Standard Ns in Silenced Version «L40
- Sound Levels at Full Load Standard NS High Efﬁ Ciency «A41
- Sound Levels at Full Load Standard Ns High Efﬁ Ciency in Silenced Version «E41
- Sound Levels at Full Load Standard Ns E with the Kit42
- Accessory AK, (L/E)42
15 Safety and Check Parameter Setting42
16 Safety Components Calibration43
17 Selection and Place of Installation45
18 Positioning45
- Minimum Technical Spaces (MM)45
19 Dimensional Tables Carpentry by 3780 (MM)46
- Ns 1402 - 1602 °°(A/E°°0046
- Ns 1402 - 1602 - 1802 °°(°/L°°0048
- Ns 1802 °°(A/E°°0050
- Ns 1801 °°(A/E°°0052
- Carpentry by 5750 8 Fans (MM) NS 2652 - 2802 °°(°/L°°0054
- Carpentry by 5750 10 Fans (MM) NS 2101 - 2401 - 2002 - 2202 - 2352 - 2502 - 2652 - 2802 °°(A/E°°0055
  - Ns 3002 - 3202 °°(A/E°°0058
  - Ns 3002 - 3202 °°(°/L°°0059
- Carpentry by 7160 (MM) Electrical Box Two Circuits NS 3402 - 3602 °°(°/L°°0060
- Carpentry by 8150 (MM) NS 3902 - 4202 °°(°/L°°0062
  - Ns 3402 °°(A/E°°0062
- Carpentry by 8150 (MM)62
  - Ns 4502 - 4802 °°(°/L°°0064
  - Ns 3602 °°(A/E°°0064
- Carpentry by 10120 (MM) NS 3902 - -4202 °°(A/E°°0066
- Carpentry by 11100 (MM)68
- Carpentry by 10120 (MM) NS 5002 °°(°/L°°0070
  - Ns 5202 °°(°/L°°0072
- Carpentry by 10120 (MM) NS 5402 °°(°/L°°0074
- Carpentry by 10120 (MM)74
  - Ns 6303 -6603 °°(°/L°°0076
- Carpentry by 13510 (MM)78
  - Ns 6903 -7203 °°(°/L°°0078
20 Hydraulic Circuit81
- External Hydraulic Circuit Recommended81
- System Load81
- Emptying the System81
21 Electrical Wirings82
- Recommended Section of Electric Cables82
- Connection to the Power Supply82
- Electrical Power Connection82
- Auxiliary Connections at the User/Installer Expense83
- Electric Data Versions «°/L84
- Electric Data Versions «A/E85
22 Control and Fi Rst Start-Up86
- Preparation for Commissioning86
- First Commissioning of the Machine86
- Season Changeover86
23 Functioning Characteristics87
- Cooling Set Point87
- Compressor Start Delay87
- Circulation Pump87
- Anti-Freeze Alarm87
- Water Fl Ow Rate Alarm87
24 Regular Maintenance87
25 Extraordinary Maintenance87
