17.1 COMPONENTS LEGEND
Model N. Name of the components Quantity
TRS252
1 Circular ange for channel connection 4
3 Electrical box 1
4 Heat recovery 1
8 Motor (50 Hz/60Hz) 2
9 Impeller 2
11 COARSE 50% Filter 2
15 ePM
2.5
95% Filter 1
12 By-pass 1
14 Main Board pCB 1
TRS352
1 Circular ange for channel connection 4
3 Electrical box 1
4 Heat recovery 2
8 Motor (50 Hz/60Hz) 2
9 Impeller 2
11 COARSE 50% Filter 2
15 ePM
2.5
95% Filter 2
12 By-pass 1
14 Main Board pCB 1
TRS502
1 Circular ange for channel connection 4
3 Electrical box 1
4 Heat recovery 2
8 Motor (50 Hz/60Hz) 2
9 Impeller 2
11 COARSE 50% Filter 2
15 ePM
2.5
95% Filter 2
12 By-pass 1
14 Main Board pCB 1
TRS652
1 Circular ange for channel connection 4
3 Electrical box 1
4 Heat recovery 2
8 Motor (50 Hz/60Hz) 2
9 Impeller 2
11 COARSE 50% Filter 2
15 ePM
2.5
95% Filter 2
12 By-pass 1
14 Main Board pCB 1
TRS802
1 Circular ange for channel connection 4
3 Electrical box 1
4 Heat recovery 2
8 Motor (50 Hz/60Hz) 2
9 Impeller 2
11 COARSE 50% Filter 2
15 ePM
2.5
95% Filter 2
12 By-pass 1
14 Main Board pCB 1
TRS1002
TRS1302
1 Circular ange for channel connection 4
3 Electrical box 1
4 Heat recovery 2
8 Motor (50 Hz/60Hz) 2
9 Impeller 2
11 COARSE 50% Filter 2
15 ePM
2.5
95% Filter 2
12 By-pass 1
14 Main Board pCB 1
