Afag CS 8/10-SD - Scope of Supply; Transport

Transport, packaging and storage
Assembly instructions EN  CS 8 - CS 12  Date 01.06.2021  Version 4.5 27–56
Scope of supply
The compact slides are supplied with an operating and assembly manual and
a safety data sheet (see scope of supply below).
Ut. CS 8 Ut. CS 12
1 x Module CS 8 1 x Module CS 12
2 x Shock absorber ASSD M5x0.5-2 2 x Shock absorber ASSD M6x0.5-1
2 x Centering bushing Ø 5x2.5 mm 2 x Centering bushing Ø 7x3 mm
2 x Special screw M3x14.8/4 mm 4 x Special screw M4x20/8 mm
2 x Special screw M3x16 mm 2 x Shock absorber ASED M6x0.5-1
2 x Shock absorber ASED M5x0.5-1
Transport
No liability can be assumed for damages caused by improper installation on
the part of the operating company.
The following conditions must be complied with for transport and storage:
 Storage temperature: 0-50 °C
 Relative air humidity: < 90%, non condensing
