Installation, assembly & setting
34 – 56 Assembly instructions EN CS 8 - CS 12 Date 01.06.2021 Version 4.5
6.2.3 Connection to the pneumatic system
When connecting the compressed air supply for the first time, make sure that
all compressed air throttles are closed.
Vent the system slowly!
The minimum compressed air quality shall comply with the specifications of
ISO 8573-1:2010.
Pneumatic connections
The CS 8/30, CS 8/60, CS 12/30 and CS 12/90 each have two pneumatic
connections (M5) on the side and rear of the base body. The CS 8/10 has two
pneumatic connections at the rear.
The unused pneumatic connections must be sealed airtight with the supplied
screw plugs.
WARNING
Danger when connecting to pneumatics!
The pneumatic system can pose various hazards that can cause serious or
fatal injuries if the work is carried out improperly.
Only qualified personnel may work with or on the pneumatic system!
The required protective equipment shall be provided and used.
NOTICE
Functional impairment to leaking compressed air connections!
Unused air connections that are not hermetically sealed lead to a pressure
loss and thus to functional impairment.
Before installing the module in a system, all unused compressed air
connections must hermetically sealed.
Perform a leak test!
