30 – 56 Assembly instructions EN CS 8 - CS 12 Date 01.06.2021 Version 4.5
Accessories CS 8 and CS 12
Article
Order Number
Centring bushing Ø4x2 mm 50035831 (CS 8)
Centring bushing Ø5x2.5x10.5 mm 11016850 (CS 12)
Initiator INI c10x28.5-Em-PNP-close-M8x1 50033432 (CS 8 + CS 12)
Initiator INI d3x22-Sn0.8-PNP-close-M8X1 50001023 (CS 8) Alternative
Elastomer shock absorber ASED M5x0.5-1 50282683 (CS 8)
Elastomer shock absorber ASED M6x0.5-1 50298509 (CS 12)
Elastomer shock absorber ASSD M5x0.5-2 50046138 (CS 8)
Elastomer shock absorber ASSD M6x0.5-1 50048428 (CS 12)
Damping element 50286941 (CS 8)+(CS 12)
Steel stop ASS 05/12 50036780 (CS 8/10)
Steel stop ASS 05/22 50045855 (CS 8/10)
Steel stop ASS 05/37 50046516 (CS 8/10)
Steel stop ASS 03/25 50465413 (CS 8)
Steel stop ASS 04/25 50465467 (CS 12)
‘Connecting plate VP 101 50041054 (CS 8)
‘Connecting plate VP 107 50041056 (CS 12)
‘Connecting plate VP 106 50077110 (CS 12)
Special screws M3x16/6 mm (2 pces) 50035812 (CS 8)
Special screws M3x14.8/4 (2 pces) 50473379 (CS 8)
Special screws M3x25/8 mm (2 pces) 50101005 (CS 12)
Socket wrench screwdriver for ASSD 05 50110796 (CS 8)
Socket wrench screwdriver for ASSD 06 50110797 (CS 12)
SDA-Support CS 8 50462186 (CS 8)
SDA-Support CS 12 50462175 (CS 12)
You will find more information on the accessories for the compact slides on
our website www.afag.com.
