9.3.2 Compressed air specifications
The compact slides are lifetime lubricated and can be operated with lubricated
or non-lubricated compressed air.
Before operating the compact slide with oil-free compressed air, make sure
that the module has never been operated with oil-lubricated compressed air!
Compressed air specification
Dry (condensation-free)
Filtered (40 μm filter for lubricated air)
Filtered (5 μm filter for non-lubricated air)
If the compact slides are operated with lubricated compressed air, we
recommend that you use the following types of oil:
oil type
Festo Special Oil
Avia Avilub RSL 10
BP Energol HPL 10
Esso Spinesso 10
Shell Tellus Oel C 10
Mobil DTE 21
Blaser Blasol 154
Oil quantity: 5-10 drops of oil per 1000 ltr. Compressed air
Viscosity range: 9 to 11 mm2/s (= cST) at 40°C, ISO class VG 10 according to
ISO 3448
Risk of damage to property!
The operation of the compact slides with oil-lubricated compressed air causes
the factory primary lubrication to be washed out. Therefore, it is absolutely
essential that the compact slides continue to be operated with oil-lubricated
compressed air in order to avoid damage to the modules.
Once the compact slides have been operated with oil-lubricated
compressed air, they may never be operated without oil-lubricated
compressed air.
