Battery charger indicator lights
The battery charger has two slots to insert a battery.
Each slot has a battery status display with indicator lights to inform the user
about the status of the inserted battery.
Table 11: Battery status display
Label Status
The battery is being charged.
Available time: Less than 30 minutes.
The battery is being charged.
Available time: 30 minutes or more but less than 60 minutes.
The battery is being charged.
Available time: 60 minutes or more.
The battery is fully charged.
Battery error.
Battery charging not possible.
Battery charger error.
Contact your local service organization.
Charging temperature is out of range.
CAUTION:
Charge the battery in the operating environment.
104 | DR 10e, DR 14e, DR 17e | Advanced Operating
0370C EN 20200228 1449
