DR 10e, DR 14e, DR 17e
Electrical connection DR Detector
Rated power supply
(powered by battery pack)
6–12V 2.73A DC
Rated power supply
(powered by power box)
100–240V 2–0.84A 50–60Hz AC
Wireless connection IEEE 802.11n (2.4 GHz/5 GHz)
Environmental conditions (during normal operation)
Room temperature between +15 °C and +35 °C
Humidity (non condensing) between 15% and 80% RH
(non-condensing)
Atmospheric pressure between 700 hPa and 1060 hPa
Environmental conditions (during storage)
Temperature (ambient) between -30 °C and +50 °C
Humidity (non condensing) between 10% and 90%
(non-condensing)
Atmospheric pressure between 700 hPa and 1060 hPa
Warming-up time
30 minutes
Dimensions
Dimensions
width x length x height
DR 10e: 268 x 328 x 15 mm
DR 14e: 384 x 460 x 15 mm
DR 17e: 460 x 460 x 15 mm
Weight (incl. battery) DR 10e: 1.47 kg
DR 14e: 2.95 kg
DR 17e: 3.65 kg
Maximum total load 300 kg over the whole detector surface
116 | DR 10e, DR 14e, DR 17e | Technical Data
0370C EN 20200228 1449
