Maximum load 120 kg on an area of 40 mm in diameter
Vibration tolerance 0.03 mm p-p (10 - 57.5 Hz)
0.2 G (57.5 - 150 Hz)
Shock tolerance 7 m/s
2
Drop limit 1200 mm (once)
Throughput (images per hour) 240 images per hour
Radio frequency band and maxi-
mum power
2400-2483.5 MHz: 100 mW (EIRP)
5150-5350 MHz and 5470-5725 MHz:
200 mW (EIRP)
Estimated product life (if regular-
ly serviced and maintained ac-
cording to Agfa instructions)
7 years
Conversion screen DR 10e C (6011/111): CsI
DR 14e C (6011/101): CsI
DR 14e G (6011/102): Gadox
DR 17e C (6011/103): CsI
DR 17e G (6011/104): Gadox
Pixel size
150 µm
Pixel matrix DR 10e: 1536 x 1920
DR 14e: 2336 x 2836
DR 17e: 2832 x 2836
Detector type amorphous silicium
Effective area size DR 10e: 230.4 mm x 288.0 mm
DR 14e: 350.4 mm x 425.4 mm
DR 17e: 424.8 mm x 425.4 mm
DR 10e, DR 14e, DR 17e | Technical Data | 117
0370C EN 20200228 1449
