1. Detector orientation (Portrait)
2. Patient orientation (AP)
3. Result on monitor
Table 3: Chest PA Landscape
R
PA
R
R
1 2 3
5
Figure 25: Chest PA landscape
1. Detector orientation (Landscape)
2. Patient orientation (PA)
3. Result on monitor
Table 4: Table with bucky
Table with bucky, portrait
Table with bucky, landscape
Note: NX is configured for a specific patient orientation, either
head left (default) or head right.
