182 Agilent 1260 Infinity DAD and MWD User Manual
9
Maintenance
Replacing Capillaries on a Standard Flow Cell
Replacing Capillaries on a Standard Flow Cell
For bio-inert modules use bio-inert parts only!
When If the capillary is blocked
Tools required p/n Description
Wrench, 1/4 inch
for capillary connections
OR 5043-0915 Fitting mounting tool
for bio-inert capillaries
Wrench, 4 mm
(for capillary connections)
Screwdriver, Pozidriv #1 PT3
Parts required Description
For parts see “Standard Flow Cell” on page 208.
Preparations Turn th e lamp(s) off.
Remove the front cover.
Remove the flow cell, see “Exchanging a Flow Cell” on page 172.
All descriptions in this procedure are based on the default orientation of the cell (as it is
manufactured). The heat exchanger/capillary and the cell body can be fixed mirror
symmetrically to have both capillaries routed to the bottom or to the top (depending on the
routing of the capillaries to the column).
The fittings at the flow cell body are special types for low dead volumes and not
compatible with other fittings.
When retightening the fittings, make sure that they are carefully tightened (handtight plus
1/4 turn with a wrench). Otherwise damage of the flow cell body or blockage may result.
