46 Agilent 1260 Infinity DAD and MWD User Manual
3 Installing the Module
Installation Information on Leak and Waste Handling
1 Stack the modules according to the adequate stack configuration.
The leak pan outlet of the upper module must be vertically positioned above
the leak tray of the lower module, see Figure 7 on page 45.
2 Connect data and power cables to the modules, see section Installing the
Module below.
3 Connect capillaries and tubes to the modules, see section Flow Connections
to the module below or the relevant system manual.
WARNING
Toxic, flammable and hazardous solvents, samples and reagents
➔ Keep solvent path free from blockages.
➔ Keep the flow path closed (in case the pump in the system is equipped with a
passive inlet valve, solvent may leak out due to hydrostatic pressure, even if your
instrument is off).
➔ Avoid loops.
➔ Tubes must not sag.
➔ Do not bend tubes.
➔ Do not immerse tube end in waste liquid.
➔ Do not intubate tubes in other tubes.
➔ For correct tubing follow instructions on label attached to the module.
