5 Operating in EI Mode
To Set Monitors for MS Temperature and Vacuum Status
108 7000/7010 Series TQ GC/MS Operating Manual
2 In the Available Monitors column, select MS High Vac and click Add to move
the selection to the Selected Monitors column.
3 In the Available Monitors column, select MS 1 Heater, and click Add to move
the selection to the Selected Monitors column.
4 In the Available Monitors column, select MS 2 Heater, and click Add to move
the selection to the Selected Monitors column.
5 In the Available Monitors column, select MS Turbo Speed, and click Add to
move the selection to the Selected Monitors column.
6 In the Available Monitors column, select MS Source Temp, and click Add to
move the selection to the Selected Monitors column.
7 In the Available Monitors column, select Foreline Pressure, and click Add to
move the selection to the Selected Monitors column.
8 Select any other monitors you want, and add them to the Selected Monitors
column.
9 Click OK. The new monitors will be stacked on top of each other in the lower
right corner of the Instrument Control window.
10 Select Window > Arrange Plots and Monitors, or click and drag each monitor
to the desired position. See Figure 31 for one way of arranging the monitors.
11 To make the new settings part of the method, select Save from the Method
menu.
Figure 31. Arranging monitors
