8CI Maintenance
To Install the CI/EI XTR Source Radiator
224 7000/7010 Series TQ GC/MS Operating Manual
2 Connect the green ground wire to the radiator. (See Figure 75.)
Figure 75. CI Source radiator
Green ground wire
Radiator
Radiator screw
Radiator screw
