Chapter 2 115
Making Adjustments
16. Frequency Response of the 8592L/94L, 8593E/94E/95E/96E, and 8594Q
Table 2-8 Frequency Response Errors
Column 1 Frequency
(GHz)
Column 2
Measuring Receiver
Reading (dB)
Column 3
CAL FACTOR
Frequency (GHz)
Frequency Response Errors Band 0
0.012 _____________________ 0.05
0.084 _____________________ 0.05
0.156 _____________________ 0.05
0.228 _____________________ 0.05
0.300 _____________________ 0.05
0.372 _____________________ 0.05
0.444 _____________________ 0.05
0.516 _____________________ 0.05
0.588 _____________________ 0.05
0.660 _____________________ 0.05
0.732 _____________________ 0.05
0.804 _____________________ 0.05
0.876 _____________________ 0.05
0.948 _____________________ 0.05
1.020 _____________________ 0.05
1.092 _____________________ 2.0
1.164 _____________________ 2.0
1.236 _____________________ 2.0
1.308 _____________________ 2.0
1.380 _____________________ 2.0
1.452 _____________________ 2.0
1.524 _____________________ 2.0
