Agilent Technologies 8590L User Manual

Chapter 12 497
Replaceable Parts
Standard-Value Replacement Components
Standard-Value Replacement Components
Table 12-2 Standard Value Replacement Capacitors
Capacitors
Type: Tubular Type: Dipped Mica
Range: 1 to 24 pF Range: 27 to 470 pF
Tolerance: 1 to 9.1 pF = ±0.25 pF Tolerance: ±5%
10 to 24 pF = ±5%
Value (pF) Part
Number
CD Value
(pF)
Part
Number
CD
1.0 0160-2236 8270160-2306 3
1.2 0160-2237 9300160-2199 2
1.5 0150-0091 8330160-2150 5
1.8 0160-2239 1360160-2308 5
2.0 0160-2240 4390140-0190 7
2.2 0160-2241 5430160-2200 6
2.4 0160-2242 6470160-2307 4
2.7 0160-2243 7510160-2201 7
3.0 0160-2244 8560140-0191 8
3.3 0150-0059 8620140-0205 5
3.6 0160-2246 0680140-0192 9
3.9 0160-2247 1750160-2202 8
4.3 0160-2248 2820140-0193 0
4.7 0160-2249 3910160-2203 9
5.1 0160-2250 6 100 0160-2204 0
5.6 0160-2251 7 110 0140-0194 1
6.2 0160-2252 8 120 0160-2205 1
6.8 0160-2253 9 130 0140-0195 2
7.5 0160-2254 0 150 0140-0196 3
8.2 0160-2255 1 160 0160-2206 2
9.1 0160-2256 2 180 0140-0197 4
10.0 0160-2257 3 200 0140-0198 5
11.0 0160-2258 4 220 0160-0134 1
12.0 0160-2259 5 240 0140-0199 6
13.0 0160-2260 8 270 0140-0210 2
15.0 0160-2261 9 300 0160-2207 3
16.0 0160-2262 0 330 0160-2208 4
18.0 0160-2263 1 360 0160-2209 5
20.0 0160-2264 2 390 0140-0200 0
22.0 0160-2265 3 430 0160-0939 4
24.0 0160-2266 4 470 0160-3533 0
