Chapter 12 503
Replaceable Parts
Standard-Value Replacement Components
A3A4 Second Converter
8592L, 8593E, 8594E, 8594L, 8594Q,
8595E, and 8596E
5086-7958
A3A5 Input Attenuator
8592L and 8593E
8592L and 8593E, (Options 026 and 027)
4
3
1
2
33321-60039
33321-60038
33321-60036
33321-60037
8594E, 8594L, 8594Q, and 8595E
8596E
A3A6 Dual Mixer
8592L, 8593E, 8595E, and 8596E
2 5086-7952
Low Band Mixer
8594E, 8594L, and 8594Q
5086-7748
A3A7 Yig-Tuned Oscillator (YTO)
8592L, 8593E, 8594E, 8594L, 8594Q,
8595E, and 8596E
3 5086-7903
A3A8 Yig-Tuned Filter (YTF)
8592L and 8593E
8592L and 8593E, (Options 026 and 027)
8 0955-0277
9 5086-7850
Switched Yig-Tuned Filter (SYTF)
8595E
8596E
2 5086-7803
5 5086-7880
A3A9 Bandpass Filter Assembly
8592L, 8593E, 8594E, 8594L, 8594Q,
8595E, and 8596E
0 9135-0252
A3A10 Directional Coupler
8593E, 8594E, 8594L, 8595E, and 8596E
1 0955-0098
A3A11 Step Recovery Diode
8592L, 8593E, and 8596E
3 0955-0149
A3A12 3 dB Attenuator
8592L, 8593E, and 8596E
3 0955-0412
Table 12-5 Assembly-Level Replaceable Parts (Continued)
Reference
Designator
Description CD Part
Number
