Chapter 12 505
Replaceable Parts
Standard-Value Replacement Components
A7 Analog Interface
8590L and 8591E
8591C
8592L and 8593E
8594E, 8594L, and 8594Q
8595E and 8596E
7
8
1
2
08590-60197
08591-60072
08592-60108
08594-60030
08595-60022
A7A1 Tracking Generator Control
8590L, 8591C, and 8591E
6 08590-60196
A8 Power Supply
All 8590 E-Series and L-Series spectrum
analyzers, 8591C cable TV analyzers, and 8594Q QAM
analyzers
8 5062-8229
Power Supply Exchange
All 8590 E-Series and L-Series spectrum analyzers
and 8591C cable TV analyzers
08590-69005
A9 Third Converter
8590L and 8591E (50 Ω input)
8590L, 8591C, and 8591E (75 Ω input)
9 08591-60081
6 08590-60344
All 8590 E-Series and 8592L spectrum analyzers,
and 8594Q QAM analyzers
8 08593-60062
A10 LO Distribution Amplifier (LODA) Control for
Option 009
8593E, 8594E, 8595E, and 8596E
3 5062-8232
Tracking Generator Control for Option 010
8593E, 8594E, 8595E, and 8596E
5 5063-0635
A11 Bandwidth Board
All 8590 E-Series and L-Series spectrum analyzers,
8591C cable TV analyzers, and 8594Q QAM analyzers
08590-60398
A12 Amplitude Control Board
All 8590 E-Series and L-Series spectrum analyzers,
8591C cable TV analyzers, and 8594Q QAM analyzers
7 08590-60105
Table 12-5 Assembly-Level Replaceable Parts (Continued)
Reference
Designator
Description CD Part
Number
