Chapter 2 57
Making Adjustments
5. Crystal and LC Bandwidth Filter
Table 2-1 Bandwidth Amplitude-Correction Map
Resolution Bandwidths BW-AMP
Correction Numbers
not used 0.00
not used 0.00
not used 0.00
not used 0.00
XTAL: 9 kHz 0.00
300 Hz 0.46
1 kHz 0.06
3 kHz −0.02
10 kHz 0.00
30 kHz 0.00
LC: 100 kHz −0.27
300 kHz −0.40
1 MHz −0.43
3 MHz −0.47
5 MHz −0.54
120 kHz −0.17
