Chapter 15 663
Service Equipment and Tools
Service Equipment and Tools
Table 15-2 Special Service Tools
Item Description Part Number Use*
1 Board puller, two prongs to lift PC boards 03950-4001 A,T
2 Extender board, pin and socket, 20 contacts (two required) 5062-1999 T
3 Extender board, pin and socket, 60 contacts 5062-2000 T
4 Extender board, 22 pin edge connector, 44 contacts 08565-60107 T
5 Injector board 5062-6421 A,T
6 Crystal bandwidth shorts (set of three) 5062-4855 A,T
Components Needed to Build One Crystal Short
6a 0.01 µF capacitor 0160-4832
6b 90.0 Ω resistor 0757-0400
6c Square, single-connector terminal (two required) 1251-4182
6d Two-terminal connector body 1251-0689
6e 3/16 inch dia. heat shrink tubing, 1 1/8 inches long 0890-0029
7 Combination wrench, 5/16 inch, with slotted box end (two required) 08555-20097 A,R
8 Combination wrench, 1/4 inch 8720-0014 R
9 Open end wrench, 15/64 inch, open end 8710-0946 R
10 Torque wrench, break-away, 10 inch-pounds, 5/16 inch, open end
40-60271
†
R
11 Cable puller, pry-bar style 5021-6773 A,T,R
12 Alignment tool, metal tip, plastic body 8710-0630 A,T
13 Alignment tool, nonmetallic tip, fiber body 8710-0033 A,T
14 Alignment tool A,T
15 TORX hand driver with required T8 and T10 bits, included in TORX
driver kit with multiple bits (See tool-tip illustration)
8710-1426 A,R
*A = Adjustment, T = Troubleshooting, R = Replacement Procedure
†
The part number provided is a non-part number. This tool can be ordered from:
Assembly Systems Inc.
16595 Englewood Avenue
Los Gatos, California 95032
(408) 395-5313
If you order a similar tool from your local supplier, it is important that the outside dimension of the wrench
be no wider than 0.518 inches. This allows the wrench to be used on semirigid cable connectors in confined
areas.
