Agilent Technologies 8712ET User Manual

Option 100 Fault Location and SRL 9-11
Characteristics
SRL Measurement Uncertainty vs Connector Fault
Table 9-8 Measurement Uncertainty with a −30 dB SRL Response
Table 9-9 Measurement Uncertainty with a −32 dB SRL Response
Corrected
Connector
System
Directivity
SRL
(Actual)
SRL (Measured)
Max Min
−30 dB −49 dB −30 dB −23.51 dB −49 dB
−35 dB −49 dB −30 dB −25.52 dB −39.75 dB
−40 dB −49 dB −30 dB −26.9 dB −34.86 dB
−45 dB −49 dB −30 dB −27.79 dB −32.98 dB
−50 dB −49 dB −30 dB −28.33 dB −32.07 dB
−55 dB −49 dB −30 dB −28.65 dB −31.6 dB
−60 dB −49 dB −30 dB −28.83 dB −31.35 dB
−65 dB −49 dB −30 dB −28.94 dB −31.21 dB
Corrected
Connector
System
Directivity
SRL
(Actual)
SRL (Measured)
Max Min
−35 dB −49 dB −32 dB −26.66 dB −48.43 dB
−40 dB −49 dB −32 dB −28.25 dB −38.73 dB
−45 dB −49 dB −32 dB −29.3 dB −35.95 dB
−50 dB −49 dB −32 dB −29.94 dB −34.7 dB
−55 dB −49 dB −32 dB −30.33 dB −34.07 dB
−60 dB −49 dB −32 dB −30.55 dB −33.74 dB
−65 dB −49 dB −32 dB −30.68 dB −33.55 dB
