Option 100 Fault Location and SRL 3-9
Making Fault Location Measurements
How to Make and Interpret Fault Location Measurements
Using the Default Calibration
To use the instrument default calibration, press
and then enter the velocity factor and cable loss parameters. (Fault
location must already be selected as the type of measurement.)
NOTE When the default cal is used, the “C” indicator does not appear on the
display.
4. Connect the Equipment
The basic equipment setup for fault location measurements is illustrated
in Figure 3-2.
Figure 3-2 Basic Fault Location Measurement Setup
CAL
