6 Oscilloscope Utility Settings
140 Agilent 1000B Series Oscilloscopes User’s Guide
To adjust a mask’s vertical failure margin
1 In the Mask menu ([Utility] > Mask Test > MaskSetting), press YMask.
2 Turn the entry knob to adjust the vertical failure margin.
The margin can be set from 0.04 div to 4.00 div.
To create a mask using the failure margin settings
1 In the Mask menu ([Utility] > Mask Test > MaskSetting), press Create Mask.
To select internal/external mask storage location
1 In the Mask menu ([Utility] > Mask Test > MaskSetting), press Location to
toggle between:
To save a mask
1 In the Mask menu ([Utility] > Mask Test > MaskSetting), press Save.
2 If the External mask storage location has been selected, use the Disk
Manager to name and save the mask file. See “Using the Disk Manager”
on page 122.
To recall a mask
1 In the Mask menu ([Utility] > Mask Test > MaskSetting), press Recall.
2 If the External mask storage location has been selected, use the Disk
Manager to select and load the mask file. See “Using the Disk Manager”
on page 122.
Internal Masks are saved and loaded from oscilloscope internal
memory.
External Masks are saved, loaded, exported, and imported from an
external USB drive.
