Getting Started 1
Agilent 1000B Series Oscilloscopes User’s Guide 29
The definitions of the front panel knobs, keys, and softkeys are as follows:
Front Panel Overlays for Different Languages
If you choose a language option other than English, you get a front panel
overlay for your language option.
To install a front panel overlay:
1 Insert the tabs on the left side of the overlay into the appropriate slots
on the front panel.
2 Gently press the overlay over the knobs and buttons.
3 When the overlay is against the front panel, insert the tabs on the right
side of the overlay into the slots on the front panel.
4 Let the overlay flatten out. It should remain secure on the front panel.
Table 5 Front Panel Controls
Controls Consists of these knobs and keys
Entry knob For the adjustment of defined controls.
Setup controls [Auto Scale] and [Default Setup] front panel keys.
File controls [Save/Recall] and [Print] front panel keys.
Horizontal controls Position knob, [Horiz] front panel key, and scale knob.
Run controls [Run/Stop] and [Single] front panel keys.
Menu controls [Cursors], [Meas], [Acquire], [Display] , and [Utility] front panel
keys.
Trigger controls Trigger [Level] knob, [Menu], and [Force Trigger] front panel keys.
Vertical controls Vertical position knobs, vertical scale knobs, channel ([1], [2], etc.)
[Math], and [Ref] front panel keys.
Softkeys Five gray keys from top to bottom on the right-hand side of the
screen, which select the adjacent menu items in the currently
displayed menu.
