40 1100 Series WS MWS Reference Manual
1 Installing the Sampler
F Row offset Distance (in mm) from the back
edge (bottom) to the center of the
first hole (A1)
G Column offset Distance (in mm) from the left edge
(bottom) to the center of the first
hole (A1)
H Column shift Offset (in mm) to Y when the rows
are not straight but staggered
l Well diameter Diameter (in mm) of the well at least 4 mm
J WeIl depth Distance (in mm) from the top of the
plate to the bottom of the well
up to 45 mm
Tabl e 13 Well Plate Dimensions (continued)
Location Description Definition Limits
NOTE
The distances need to be measured with high precision. It is recommended to use calipers.
