Agria 3400 - Differential Gear

agria Two-Wheel Tractor 3400; 3400 KL 35
Differential Gear
Differential can be locked in severe conditions to
improve traction. The lever for differential lock and
unlock is on the right side of the handle bar. On
the lever there is a pawl to lock the disengaged
differential.
I
Because of the tractor’s easy
steering, the differential should
be unlocked when driving with the trailer
mounted, especially in curves.
Keep differential locked only as long as neces-
sary.
Engaging the Differential Lock:
(rigid wheel shaft)
On the move:
l Release throttle.
l Pull lever for differential lock slightly (B/10 or
D/10).
l Unlock pawl (B/11 or D/11).
l Slowly release lever while pressing the throt-
tle.
Disengaging the Differential Lock:
l Pull lever for differential lock until pawl locks
into place.
3. Devices and Operating Elements
Differential Version
3
B/11;
D/11
B/10;
D/10
Pawl locked = differential
lock disengaged
