72 agria Two-Wheel Tractor 3400; 3400 KL
Machine
Oil level
Check in the clutch housing and
in the drive every time before starting and after
every 50 operating hours (oil dipstick and opening
for oil filling) (10 or 18). With the tractor parked in
horizontal position, the oil level is between the
notches “max” and “min”.
l
Screw out oil dip-stick, clean with clean cloth
and screw back in.
l
Take dip-stick out again and read oil level, refill
transmission oil, if necessary.
Depending on the version, there may also be an
inspection screw on the clutch housing in place
of the oil dipstick; for this check the oil level as
follows:
l
Unscrew the inspection screw. If the machine is
in a horizontal position the oil level must be at the
level of the inspection screw opening, top up with
gearbox oil where necessary.
- Replace oil dipstick or re-screw and tighten
inspection screw.
Oil change
l
In the clutch housing after the first 8 and
then after every 200 operating hours
l
in the
gearbox after the first 50 and then after every
200 operating hours, in each case in a warm state
after operation carry out the following:
Clean oil filler plug (10 bzw. 18) and drain plug
(20 bzw. 25) as well as surrounding parts.
Change the oil and dispose of properly.
The oil drain screw (25) on the clutch housing is
fitted with a magnet. Any metal dust on this must
be removed. Screw and tighten the oil drain screw
on the clutch housing.
5. Maintenance
66
66
6 (8; 50 h) 200 h
66
66
6 A; 50 h
Clutch housing
Version with inspection screw
Version
with oil
dipstick
1018
2025
I
Check sealing washer for good condition and exchange,
if necessary!
- For transmission oil quality refer to “Specifications”
