60 agria Two-Wheel Tractor 3400; 3400 KL
Driving with
Mounted Trailer
When driving the two-wheel tractor on
public roads (whether with or without
trailer), adhere to traffic rules, e.g. in re-
spect of tail lights.
I
Only differential version ma-
chines fitted with 5.0-10
drive wheels are permitted to tow a
trailer on public roads.
The two-wheel tractor must be
equipped with a generator and the
trailer with lighting and flash-lights
in accordance with national traffic
rules.
Besides, the operator is required to
carry a type approval both for the two-
wheel tractor and the trailer attached.
Required Accessories:
1 pair of drive-wheels 5.00-10
.............................. Item No. 0190 112
1 pair of wings
.............................. Item No. 3424 011
1 two-wheel trailer ..............................
650 kg permissible total weight
................................Item No. 3481121
(Recommended gearbox version:
4th gear = 16 .9 km/h)
W
It is not allowed to ride on the
trailer if attached to a steering
brake clutch machine – risk of acci-
dent!
Preparations
l Fit drive-wheels (refer to page 41).
l Fit wings to gearbox housing with at-
tachment bolts (A/10; C/10; E/10; G/10).
Coupling
l Mount trailer drawbar (1) onto trac-
tor hitch (A/6; C/6; E/6; G/6).
l Insert socket pin (A/8; C/8; E/8; G/8)
and secure with linch pin (A/7; C/7; E/7;
G/7).
l Connect cable and connector (2) to
socket (A/18; C/18; E/18; G/18) of two-
wheel tractor.
4. Commissioning and Operation
4
