24 agria Multi-Purpose Machine 400P
3. Devices and Operating Elements
Rigid position Differential position
1 Differential hub
2 Wheel flange
3 Lubrication nipple
4 Clip
1 Drive-wheel
2 Wheel weight
3 Star washer
4 Hex bolt
3
Differential Hubs
The differential effect of hubs is factory-
set.
However, you can also fit them rigidly.
For this purpose, proceed as follows.
l Remove clip (4) with a pair of pliers.
l Slightly pull the wheel flange (2) out-
wards. Twist it until the cam is between
both pins.
l Then push the wheel flange all the
way onto the differential hub and fit the
clip.
l Use a grease gun to lubricate lubri-
cation nipple (3) (with Bio-grease) af-
ter every 50 operating hours or after
pressure cleaning.
Wheel weights
Drive-wheels 4.00-8 with differential
hubs can be fitted with wheel weights
(Item no. 0421 011).
Fitting wheel weights
To fit wheel weights (2) onto the wheel
flange, use hex bolts(4) and star wash-
ers (3). (Torque 80 Nm)
