Agria 5400 - Central Brake Operation

Edition 02.97 Power Mower 5400 23
Steering Handle Height
Adjustment
l Loosen both lock nuts and hex head
bolts (A) until notches (B) are free.
l Adjust left and right steering handles
to desired height and lock into appro-
priate notch.
l Tighten lock nuts and hex head bolts.
3. Devices and Operating Elements
Central Brake (optional)
To slow down or park power mower on
hilly ground, use the combined central
hand brake.
l Central Brake
Clockwise swivel eccentric lever (B/7)
backwards – brakes act on both drive-
wheels.
Release eccentric lever and the lever
swivels back to original position – brake
is released.
l Hand Brake
Clockwise swivel eccentric lever (B/7)
backwards beyond the dead centre.
Eccentric lever automatically comes to
a stop – both drive-wheels are blocked.
To release hand brake, swivel eccentric
lever back to original position – brake is
released.
