3 Devices and Operating Elements
Remote-controlled All-electric Tool Carrier agria 9700e
Only lash the machine at the specified points (1). Lashing
to other points can cause damage to the machine.
Loading straps must be fastened to the attachment points (1)
for towing, recovery, and lashing for safe transport and loading
the machine.
Check the loading straps for damage and replace them if nec-
essary!
Do not use sharp-edged load carrying equipment (e.g. sharp-
edged hooks, eyes etc.)!
As soon as a mounted implement has been attached to the
machine, pay attention that for transporting purposes, the
mounted implement is placed on the floor of the means of
transport. Also lash the mounted implement to avoid transport
damage. Observe the mounted implement’s operating instruc-
tions for this.
Only hang the machine on a lifting device at the marked
points. Attaching it to other points can cause damage to
the machine.
Unscrew the service flap (A/24) at the centre of the machine to
lift the machine with a crane. Undo the five half-round screws
TX30
Please note that the machine can tilt when it is lifted, especially
if no mounted implement is attached to the machine. The
weight of the mounted implement also influences whether and
how far the machine will tilt when it is lifted.
As soon as the machine no longer needs to be lifted, mount
the hood and tighten the five half-round screws TX30 hand-
tight.
Never stay under a suspended load and never pass under-
neath it. Danger to life!
