Remote-controlled All-electric Tool Carrier agria 9700e
Check the crawler track tension every day
The crawler tracks must be firmly positioned on the wheels.
They may need to be tensioned or loosened.
Setting the crawler track tension
Then set the crawler track tension using the clamping nut
(A/3.1).
Use the open-ended spanner AF 36.
Set the tension of the crawler tracks so that a dimension of 24
- 27 mm is reached, measured from the cup spring assembly
at the front to the frame.
Insufficient track tension is the main cause of loosing
the tracks.
Intensive sun radiation during work leads to a significant
elongation of the crawler tracks and thus to a reduction of the
track tension.
