6 Troubleshooting and Remedies
54
Remote-controlled All-electric Tool Carrier agria 9700e
Error codes
Error code
Name
Description
Instructions
Power electronics
0x4DC3
Critical power supply
Battery voltage below undervoltage limit
Check the power supply on the corresponding
motor controller.
0x4602
Motor controller too hot
Power reduction due to excessive temperature
at the inverter
Wait until motor controller has cooled down to
standard temperature
0x52C2
Overcurrent
Motor current was above maximum permissible
value
Check the mechanical components for power
transmission to the mounted implement, e.g. its
ease of movement and the mechanical sound-
ness.
0x4981
Wrong operation joystick
Joystick is deflected by more than 20% when
the machine is switched on
Do not operate the joystick during the activation
procedure.
0x45C3
Shutdown due to un-
dervoltage
Battery voltage below undervoltage limit
Charge battery or reduce current consumption
0x4603
Thermal power reduction
engine
An excessive engine temperature has lead to a
power reduction
Wait until engine has cooled down to standard
temperature.
Remote control
0x8120
CAN error
0x8130
Heartbeat error
Heartbeat was not received
Check CAN bus connection. Are all network par-
ticipants active. Check status LEDs of the indi-
vidual components.
0x2000
Current
Overcurrent
Check the cables on the receiver and the re-
ceiver itself.
0x3000
Voltage
Voltage
Check the voltage supply of the receiver.
Central control unit
0x8130
Heartbeat error
Heartbeat was not received
Check CAN bus connection. Are all network par-
ticipants active. Check status LEDs of the indi-
vidual components.
0x5001
Total current consumption
max.
Total current of the CCU has been exceeded
Check for short circuit at the CCU outputs.
0x5022
CCU temperature warning
The temperature of a component from the table
page 19 has exceeded the warning threshold
Check the temperatures on page 3 of the re-
mote control. If the error occurs frequently at
light load, clean the air filter and check the ca-
ble.
0x5023
CCU temperature warning
“The temperature of a component from the table
page 19 has exceeded the threshold for power
reduction”
Reduce the load on the machine.
0x5044
CCU temperature warning
“The temperature of a component from the table
page 19 has exceeded the critical temperature
threshold”
Switch off the machine and wait until the corre-
sponding component has cooled down.
Rechargeable batteries
0xXXaX
Not all rechargeable bat-
teries in the system are ac-
tive
- agria customer service -
0x4200
Low temperature charging
- agria customer service -
0x4201
High temperature charging
- agria customer service -
0x4202
Low temperature discharg-
ing
- agria customer service -
0x4203
High temperature dis-
charging
- agria customer service -
0x2000
Overcurrent
- agria customer service -
0x2001
Short circuit
- agria customer service -
0x3000
Overvoltage
- agria customer service -
