Appendix “C” – SmartyCam cables Pinout
4
5
2
3
7
4
5
2
1
3
Racing Data Power
N. rev. / Rev. N.
Descrizione / Description
Data / Date
Firma / Signature Contr. da / Ckd. by
Rif. / Ref.
Q.tà/Q.ty
Material / Material N. articolo / Item N.
Progettato da / Designed by Contr. da / Ckd. by Approvato da / Approved by Nome file / File name Data / Date Scala / Scale
Titolo / Title
N. disegno / Drawing N. Rev. / Rev. Foglio / Sheet
04.566.07 (lenght 2 m)
04.566.06 (lenght 4 m)
1 of 1
L.I.
Adapter CAN cable for SmartyCam: available lenghts 2m/4m
1
6
Adapter CAN cable for SmartyCam available lenghts: 2m/4m
7 pins - Binder 712
male connector
5 pins Binder 712
male connector
7 pins Binder 712
male connector
Solder termination view
7 pins Binder 712
male connector pinout
1
2
3
4
5
6
7
CAN+
GND
+Vb
CAN-
Vb ext
n.c. n.c.
1
2
3
4
5
CAN+
GND
+Vb
CAN-
Vb ext
5 pins Binder 712
male connector
Solder termination view
5 pins Binder 712
male connector pinout
